35W GaN Charger

Product Details

SPECIFICATIONS

Type:ASGaN15

Typical output:USB-C1/USB-C2:5V 3A/9V 3A/15V 2.33A/ 20V 2A

USB-C1+USB-C2:5V 3A/9V 2.22A/12V 1.5A+5V 3A/9V 2.22A/12V 1.5A

Output voltage:5V/9V/15V/20V

Output current:0.1A-3.0A

Rated input voltage:100-240Vac

Input voltage range：90-264Vac

Input frequency:50/60Hz

Input current:1.2A(rms)max@90Vac

Incrush current:30A max@240 Vac

No load power consumption:0.3W max

Energy class:VI

Safety standard：IEC/UL/EN62368(GB4943)

EMC standard：EN55032，EN55035,EN61000

Part 15 Subpart B

CISPR 32,CISPR24



WORKING ENVIRONMENT

Operation temperature:-10℃～25℃

Storage temperature:-20℃～70℃

Humidity:5%～95%RH
