Working Environment
Operation temperature: -5鈩儈45鈩
Storage temperature: -20鈩儈70鈩
Humidity: 35锕獈85锕猂H
Specifications
Typical output: 12V2A
Output voltage: 4.2V~24V
Output current: 0.1A~2A
Input voltage: 90~264V AC
Input frequency: 50/60 Hz
Input current: 600mA(rms)max@90V AC
Inrush current: 30A max@240V AC
No load power consumption: 0.075W max
Energy class: VI
Certifications
CB / CE / ETL / FCC / GS approval
CB (IEC 60950-1:2005, IEC60065:2014)
CE LVD (EN60950, EN60065)
CE EMC (EN55013, EN55020, EN55022, EN55024, EN61000-3-2, EN61000-3-3)
ETL (UL60950-1, CSA C22.2 #60950-1; UL60065, CSA C22.2 #60065)
FCC (FCC Part 15, Subpart B:2014)
GS (EN60950-1:2006, EN60065:2014, AfPS GS 2014:01)
